OTR Titan Axles

HUB & STUB 1000KG LANDCRUISER

50MM SQUARE X 400MM STUB (6 STUD JAPANESE PATTERN)

Product Code: 2HSLC400T
  $310.00
EACH inc GST
Afterpay Logo
4 payments of $77.50
In Stock Low Stock Contact Us Please See Attributes 52
Increase value Decrease value

  • Detail
  • Parts & Codes
  • Downloads

OTR® Titan Stub Axle Assembly
AH40-6/139.7 (Japanese 6 stud)


OTR® Australian made stub axle designed for heavy duty off-highway agricultural and industrial trailer applications.

AXLE
MODEL		 CAPACITY
 @25kph		 STUB
MATERIAL		 STUD
NUMBER		 STUD
SIZE		 PCD Ø
(MM)		 SPIGOT Ø
(MM)		 FLANGE Ø
(MM)		 STUB SIZE
(MM)
AH40 1,000kg 50MM SQUARE 6 1/2" UNF 139.70 92 183 400

WHEEL
FITMENT		 JOURNAL
INNER Ø		 JOURNAL
OUTER Ø		 BEARING
INNER		 BEARING
OUTER		 SHIPPING
WEIGHT		 PART
NUMBER
TOYOTA 40 30 30208 30206 11 033.011.010


Features
  • Australian Made
  • Bolt on dust cap
  • Replaceable seal wear ring
  • Guest style seal
035.011.010
