Narva ‘Rotary’ Battery Master Switch With Removable Keyed Knob

The ‘Rotary’ Battery Master Switch is a compact switch at just 45mm round, requiring a mounting opening of just 23mm diameter. Features an easy turn knob, ideally suited for use with passenger cars, light trucks, and stationary engines.

Features

• Removable keyed knob
• 45mm Diameter
• Requires 29mm diameter mounting opening
• Include alternative insert
• Ideal for passenger cars, light trucks, and stationary engines

Specifications

• Current Draw:
• 1000A @ 12V, 5 Sec.
• 500A @ 24V, 5 Sec.
• 100A @ 12V Continuous Load Maximum
• 50A @ 24V Continuous Load Maximum
• Terminals: 2
• Power Rating (Amp): 100A @ 12V
• Switch Action: Off – On
• Voltage: 12/24V
• Lamp Colour/s: Not Applicable
• Poles: 1
• Positions: 2
• Switch Type: Battery Master / Isolation
• Switch Illumination: Non Illuminated
• Packaging Type: Blister Pack
• Weight: 0.07kg
