C&M replacement complete feeder house chain assembly to suit the front feeder house on White combine harvesters.This is a set of three (3) replacement chains fitted with electroplated 6mm serrated U-Bar slats with wider spacing than the original chain.
This complete chain assembly is supplied with connectors and half links for each strand. We supply these chains in Australia from premium grade pin chain and quality electroplated 6mm U-Bar slats. We guarantee the quality of these unit, however we recommend you fit a new sprocket at the time of installation.
*Note: This assembly is supplied with 22 bars in an 8-4-8 patten. The original assembly is fitted with 42 bars in a 4-2/4-4 patten. We supply the assembly with less bars due customer requests to reduce weight and improve feeding.
Part Numbers
- 31-1667863 31-1667853 - Complete Assembly
- 31-1667870 31-1572100 - Right Hand Chain Only
- 31-1667890 31-1572120 - Center Chain Only
- 31-1667880 31-1572110 - Left hand Chain Only
Models
| Series |
Models |
Serial/Year |
| White / New Idea 7000 Series |
7600, 7800 |
|
| White / New Idea 8000 Series Harvest Boss |
8600, 8700, 8800, 8900 |
|
Features
- Premium grade pin chain
- Zinc plated 6mm seratted U-Bar
- Connectors & Half Links Included
- Bolted assembly ready to install
