Aftermarket centre feed belt to suit Macdon & Case IH draper feed deck. Manufactured by WCCO in the USA, this centre feed belt measures 59.5" wide x 85.75" long with straight cleats, side V guide, and comes with joiner.
Part numbers
Models
| Series |
Models |
Serial/Year |
| Macdon Combine Adaptors |
872, 873 |
56" Feed Deck Width |
| Macdon 900 Series |
962, 963, 964, 970, 973, 974 |
| Case 10 Series |
1042, 1052 - Not sure if these were supplied with 59" deck |
| Case 20 Series |
2042, 2052, 2062 |
Combine Fitment
| Model/Series |
Comment |
| John Deere |
* Some John Deere CTS Combines with dust shields in rice applications may have been converted to 45” decks. Check feed draper width carefully before ordering parts that are specific to one deck size.
|
| New Holland CX |
|
| Lexion 460, 465, 480, 485 |
|
| Challenger 670 |
|
| Massey 9790 |
|
Features
- Deck Width 56" (1422mm)
- Size 59.5" W x 85.75" L (1511mm W x 2178mm L)
- Supplied with connector
- USA made WCCO Raptor
- Strength and reliability
WCCO’s patented RAPTOR™ Belting uses 100% polyester filament fabric with a friction coating capability with higher tensile, tear, and puncture resistance. RAPTOR™ draper belting has higher strength properties, superior durability and also features an innovative teardrop-shaped fiberglass reinforcement rod inside of the cleat for increased stiffness, making it more significantly stiffer in the cross direction than its competition.
