Harvestaire aftermarket extended length top sieve to suit Case-IH long sieve mid series combine harvesters. This top sieve is a full anti rattle with nylon bushing fixed in every pivot point of frame.
Airfoil Top Sieves have a unique Louvre design that divides the airflow and creates a bed of air jets which floats chaff up off the surface allowing heavier grain to easily separate and fall.
Part numbers
- 1322467C1, 138625A1, 87710708, 87492183, 1322467C2, 1322467C3, 1322467C4, 1322467C5, 1322467C6, 87710707
Case Models
| SERIES |
MODELS |
SERIAL/YEAR |
| Case 16 Series |
1640E, 1680, 1680E, 1688 |
|
| Case 21 Series |
2188 |
|
| Case 23 Series |
2377, 2388, 2388 X-Clusive, |
|
| Case 25 Series |
2577, 2588 |
|
| Case 88 Series |
5088, 6088, 7088 |
|
| Case 130 Series |
5130, 6130, 7130 |
|
| Case 140 Series |
5140, 6140, 7140 |
|
| Case 150 Series |
5150, 6150, 7150 |
|
Features
- For machines with long sieve
- Full anti rattle nylon bushed
- Galvanised louvres
- Measure 60" L x 75.24" W
- Slats 1-1/8"
