A&I Products® Case-IH® Compatible Stainless Steel Loading Auger

Restore efficient grain handling with this premium A&I Products® Case-IH® compatible stainless steel loading auger. Designed as a direct-fit replacement for selected Case-IH® Axial-Flow combine harvesters equipped with the Advanced Farming System (AFS), this quality aftermarket auger is manufactured from corrosion-resistant stainless steel to provide dependable grain transfer and long service life in demanding harvesting conditions.

The loading auger transfers clean grain from the grain bed into the clean grain elevator. Over time, abrasive crop material can wear the auger flighting, reducing conveying efficiency and increasing stress on surrounding drive components. Replacing a worn loading auger helps restore grain flow, maximise harvesting performance and reduce costly in-season downtime.

Case-IH® OEM Cross-Reference

Replaces OEM Part Numbers:
320724A3, 222801A2, 222801A3, 222801A4, 320724A1, 320724A2

A&I Products® Part Number:
A-320724A3

Compatible Case-IH® Combine Harvesters

Technical Specifications

• Brand: A&I Products®
• Component: Loading Auger
• Material: Stainless Steel
• Auger Length" 47.25" (1200mm)
• Application: Clean Grain Loading System
• Suitable For: Advanced Farming System (AFS) combines
• Replacement Type: Premium aftermarket direct-fit replacement

Features & Benefits

• Quality A&I Products® aftermarket replacement
• Corrosion-resistant stainless steel construction
• Suitable for Case-IH® Advanced Farming System (AFS) combines
• Direct replacement for worn OEM loading augers
• Maintains smooth grain transfer into the clean grain elevator
• Helps maximise harvesting efficiency and crop flow
• Precision manufactured for excellent fit and reliable operation
• Ideal for preventative maintenance and combine rebuilds

Expert Maintenance Review

Loading augers operate continuously in abrasive grain and crop residue. Inspect the auger flighting for thinning, sharp edges and reduced flight height, particularly around the discharge area where wear is most common. Replacing worn augers before harvest helps maintain conveying capacity while reducing unnecessary wear on the clean grain elevator, bearings and drive components.

Installation Tip

While the auger is removed, inspect the supporting bearings, shafts, seals and drive components for wear or misalignment. Servicing these components at the same time helps maximise the service life of the replacement auger and ensures reliable operation throughout the harvest season.

Collier & Miller stocks a comprehensive range of genuine A&I Products® replacement parts for Case-IH® combine harvesters, with fast Australia-wide shipping.
