Case-IH® Compatible Stainless Steel Clean Grain Auger Trough Liner Kit
Optimise your grain handling system with this high-quality stainless steel clean grain auger trough liner kit. Specifically engineered for later-model Case-IH® Flagship Axial-Flow combines, this high-performance kit is the professional solution for repairing worn components in the primary clean grain circuit.
Manufactured by IHLE Fabrications in the USA, this kit includes a set of three full-length (69.5") weld-in troughs and comes complete with matching door covers. By utilizing heavy-duty stainless steel, this extended wear solution offers vastly superior abrasion resistance compared to standard carbon steel. This strategic refurbishment allows you to avoid the high cost of a complete housing replacement, keeping your machine in top condition for a significantly longer service life.
Critical Serial Number Check
This kit is specifically designed for Flagship models manufactured After Serial Number YDG222000. Please verify your machine's identification plate to ensure correct fitment before ordering, as the trough length differs significantly from earlier models.
Case-IH® OEM Cross-Reference
Compatible with Part Numbers: AE138, IF1102177K
Auger Trough Liner Compatibility: Case-IH Flagship Series
| Series |
Models |
Serial Range |
| Case 230 Series |
7230, 8230, 9230 |
After SN - YDG222000 |
| Case 240 Series |
7240, 8240, 9240 |
| Case 250 Series |
7250, 8250, 9250 |
Technical Specifications & Features
- Manufacturer: Precision made in the USA by IHLE Fabrications.
- Material: High-grade Stainless Steel for maximum abrasion resistance.
- Dimensions: 69.5" Total Length (Weld-in full troughs).
- Kit Contents: Set of 3 Stainless Trough Liners and complete Door Covers.
- Refurbishment: Engineered specifically to repair worn components and prevent grain loss.
- Wear Rating: Extended wear configuration designed for high-capacity harvesting.
- Dispatch: Available for fast Australia-wide shipping from Collier & Miller.
Expert Maintenance Review
The clean grain auger trough is a high-duty friction point where high volumes of threshed grain are moved toward the elevator. Standard steel troughs are prone to extreme abrasion thinning, eventually developing pin-holes that cause grain loss. We recommend inspecting the floor of the trough for "paper-thin" sections during every preventative maintenance check to identify worn components before they lead to downtime.
Upgrading to this high-performance stainless steel liner kit is a strategic choice to save money on major structural repairs. The high-density stainless surface maintains its structural thickness far longer than painted steel, ensuring smooth grain handling and keeping your system in top condition for a longer service life.
Installation Tip: Precision Welding
This is a weld-in high-strength refurbishment kit. For the best result, ensure the original trough is thoroughly cleaned of all residue and rust before installation. This is the ideal time to check your clean grain augers for flighting wear to ensure your entire handling system is restored to maximum capacity.
