Aftermarket cereals and small grain extended wear helical concave set to suit Case-IH flagship combine harvesters. This kit contains 1 x Left hand and 1 x Right Hand Helical bar concave. Placed in the first position of the rotor, these helical concaves give you an improved crop flow to the rotor. With the bars and wires running diagonally in the concave, the material entering the rotor hits the concave at a right angle. This prevents unthreshed grain, and also white heads.The extended wear gives you more life and less wear in the concave saving you time and money.

Small Wire Concaves are for small grain harvest, grass seed and canola. It is normally installed upfront for all crops and conditions, except for large size crops.

Part numbers

• Right Hand 86976418HB
• Left Hand 86976420HB

Position

• Position 1

Series	Models	Serial/Year
Case 10 Series	7010, 8010, AFX8010
Case 20 Series	7120, 8120, 9120
Case 30 Series	7230, 8230, 9230
Case 40 Series	7240, 8240, 9240
Case 50 Series	7250, 8250, 9250

Features

• Extended wear
• Complete kit includes 1 x Left & 1 x Right concaves
• Aggressive threshing
• 35 Wires, 7.3mm gap between wires

Click & Ship Bulky Item

This product can be added to the shopping cart, however if 'Click & Ship' is selected the cart will advise it cannot process the line. Details of how to proceed is as follows:

• Please contact us to arrange a quotation for supply and delivery of this bulky item.
• Collier & Miller will respond and provide product availability and a quote to supply including any freight charges, before accepting payment and processing your order.
• Delivery of bulky item may not be available to all areas within Australia.
• Where your order has multiple Items that include a bulky Item, the cart will only allow processing of non-bulky items. Remove bulky items as indicated in the shopping cart and proceed to checkout non-bulky items.
• For bulky Item, Collier & Miller will advise on an estimated delivery date once a delivery quote has been agreed on. Please be aware that Bulky Items may require the use of delivery agents that do not have a standard delivery schedule.may incur an additional delivery fee which will be specified on the website.

Click & Collect Bulky Item

This product can be added to the shopping cart, if the option 'Click & Collect' is selected the order can proceed to checkout and payment. The products will be available once you have received a confirmation e-mail advising the order is ready. Order can be collected from the following address;

Collier & Miller Pty Ltd
43 Jondaryan Avenue
Griffith NSW 2680 Tel: 02 69694500

Directions on-site will advise where to proceed for pickup.

Terms & Conditions

For further information refer to Collier & Miller terms and condtions.

86976420HB 86976418HB
