C&M GRADER BLADE 3600 SERIES

HEAVY DUTY LINKAGE MOUNT BACK BLADE, 12' (3600MM) BLADE

Product Code: CMHDBB12
P.O.A.
Per EACH inc GST



In Stock Low Stock Out Of Stock Please See Attributes 0
  • Product Detail
  • Downloads

The perfect Heavy Duty hydraulic controlled 3 Point Linkage Back Blade that is ideal for on-farm grading and levelling jobs.Designed for tractors with category 3 or 4 linkages and with power outputs of above 150 Horsepower. This is a serious solution for grading, forming and levellingjobs that need to be done on farm.

A class above other back blades on the market, our engineers have designed and built an implement that is truly heavy duty. With a huge range of movement controlled through your tractors hydraulic remotes.The operator can use the blade to perform a multitude of actions. The three axis control allows a combination of height, tilt and slew. Specific features include;

  • FEATURES & BENEFITS
  • Cat 3 & 4 Linkage mount
  • Minimum 150 HP Tractor size
  • 3 Axis hydraulic control tilt-lift-slew
  • Manufactured in Australia
  • Heavy Duty 12mm Mould Board
    Fully Welded Construction
    Replaceable Cutting Edges
    Full Hydraulic Operation
    Extra Heavy-Duty Swivel Pin for smooth operation


Ideal for on-farm earthworks like building roadways, leveling channell banks and creating drains. We manufacture this equipment in our engineering facility.
