Orbit motors convert hydraulic energy (pressure, oil flow) into mechanical energy (torque, speed).
Hydraulic orbit motors operate on the principle of an internal gear (rotor) rotating within a fixed external gear (stator).
The internal gear transmits the torque generated by the application of pressure from hydraulic oil fed into motor which is then delivered via the motor's output shaft.
Orbit motors have high starting torque and constant output torque at wide speed range.
| CC/Rev |
80.3 |
| Mount |
Q Mount - 4 Bolt |
| Shaft |
1" Shaft with 10mm Cross Hole |
| Ports |
2 Port 7/8 UNO |
| Rotor Width L1-mm |
14 |
| Speed Max Cont RPM |
747 |
| Flow Max Cont LPM |
60 |
| Pressure Drop Max Cont Bar |
140 |
| Inlet Pressure Max Cont Bar |
140 |
| Torque Max Cont Nm |
152 |
| Weight Kg |
6.7 |
