SMC MECHANICAL VALVE 3/2 TOGGLE LEVER (BSP-F1/8 PORTS) VM430-01-08

TOGGLE LEVER (BSP-F1/8 PORTS) VM430-01-08

Product Code: VM4300108

Detail

SMC (3-Way 2-Position) Toggle Valve - Single Action

SMC VM400 series is a compact toggle actuated 3-way x 2-position mechanical valve. Ports are located on the side of the valve and allow the exhaust port is threaded to allow for noise countermeasures.

The valve is used to fill a cylinder, and also to exhaust it afterwards, so that a new working stroke can be realized. Therefore, a valve with two ports would not be adequate. Venting requires a third port.

Specifications

3-way normally closed or normally open port option
Operating Pressure -100kPa to 1.0 Mpa
Port 1/8"-F BSP

Features

Medium size with threaded ports
Ports located on each side
Toggle actuator

Typical Uses

Control a single action cylinder (fill cylinder & exhaust after)
Ideal for water truck valve actuators
