FRA8 Forward Reverse Gearbox (Ratio 1:1)
Ideal for use on grain handling augers the FRA8 series forward and reverse gearbox allows for convenient rotational change for your grain auger. The gear selector allows f or f orward, reverse or neutral movement. Please note the standard model offered is the FRA8 which is a 3 shaf t T design box.
Part Number
| Specifications |
540RPM |
1000RPM |
| Gear Ration |
1:1 |
1:1 |
| Power Rating |
22Kw @ 540RPM (30Hp) |
33Kw @ 1000 RPM (46Hp) |
| Input Torque |
389Nm @ 540 Rpm |
315Nm @ 1000Rpm |
| Output Torque |
389Nm @ 540 Rpm |
315Nm @ 1000Rpm |
| Shafts |
30mm Plain x 8mm Key |
|
| Lubricant |
SAE90 |
|
Warning: The gearbox shafts should be stationary before selecting gears. Any movement of the shafts during this procedure can cause unnecessary wear of the selector mechanism and will shorten the working life of the gearbox.
- Includes mouting holes for safety covers
- Mounting boll pattern allows for replacement of Andiline FR100 model gearboxes.
