Case-IH® Compatible
Extended Wear Transition Cone
A&I Aftermarket heavy duty transition cone with stainless steel vanes to suit Case IH flagship combine harvesters. This heavy duty transition cone comes with pre-fitted stainless steel vane's and designed for combines with enhanced cleaning system. Stainless steel vanes improve feeding from the feeder to the rotor cage.
* Check height dimension of your transition cone to confirm compatibility. The A&I cone has a nominal height of 400-403mm when measured from the large flange face to the small flange face.
Part numbers
- High Wear 47843259 87382439
- Replaces Standard Wear 47843254 87318719 87350843 87350845
| Series |
Models |
Serial/Year |
| Case-IH® 10 Series |
7010, 8010 |
> HAJ106401 |
| Case-IH® 10 Series |
AFX8010 ** Note one external mounting flange on this cone may need to be relocated prior to installation. |
| Case-IH® 120 Series |
7120, 8120, 9120 * |
| Case-IH® 230 Series |
7230, 8230, 9230 |
|
| Case-IH® 240 Series |
7240, 8240, 9240 |
|
| Case-IH® 250 Series |
7250, 8250, 9250 |
|
Features
- A&I extended wear
- Stainless steel vanes
- Recommended for all crops
- For models with enhanced cleaning systems
*The A&I transition cones have a nominal height measurement of 403mm from the outside of the large flange to the outside of the small flange. This measurement is performed with the cone positioned with the large flance face down on the floor and a straight edge placed across the small flange. The 403mm is the vertical measurement from the floor to the bottom of the straight edge.
