CASE-IH RETURN GRAIN CHAIN KIT

1688 112L 28P 7T

Product Code: KIT1688-R
  $952.50
EACH inc GST
Afterpay Logo
4 payments of $238.13
In Stock Low Stock Contact Us Please See Attributes 10
Increase value Decrease value

  • Detail

CASE-IH® Compatible
1688 Tailings Grain Elevator Chain Assembly (7T Sprockets)


C&M aftermarket tailings (returns) grain chain assembly kit to fit CASE-IH 1688 combine harvester where the assembly is supplied with 7 Tooth Upper & Lower Sprockets.

Part Number
Brand Item Part Number
CASE-IH 130114C91 ELEVATOR CHAIN C550, 112 Links x 41.4mm = 4636.8mm; CONVEYOR ASSEMBLY - elevator
CASE-IH 168683C1 SPROCKET; - upper chain, conveyor
CASE-IH 1302200C1 SPROCKET; - lower chain, conveyor

Chain Features
  • Quality CA550 Chain
  • Quality waterjet cut paddles
  • Same spacing as the OEM chain
  • 1 x Connectors 2 x Offset Links
  • High tensile fasteners
  • Ready to install
Sprocket Features
  • C&M Made in Australia
  • Electroplated finish
  • Grade 1045 sprocket material
  • Upper Sprocket 7T x 1.00" Bore x 1/4" Key
  • Lower Sprocket 7T x 1.25" Bore x 5/16" Key
Case-IH® Compatible ensures the C&M aftermarket part will fit the machine model stated based on our research and customer feedback. C&M parts are an aftermarket product and do not make a claim to be a genuine Case-IH® part. It is recommended prior to ordering you should verify the parts will fit your equipment. Case-IH® is a registered trademark of CNH Industrial America LLC

Kit Components
Code
Code
Qty
CM624
CASE IH RETURN GRAIN CHAIN
1
WI63
CASE IH ELEVATOR UPPER SPRKT
2
