TOHO ELEC CHAIN HOIST 5T/3M
The TOHO ELEC CHAIN HOIST 5T/3M (3-Phase) is designed to deliver powerful, efficient lifting capabilities for the toughest tasks. With an impressive 5-tonne (5000kg) capacity and a 3-meter standard lift, this hoist is powered by a robust 3.0kW dual-speed 3-phase motor. Offering lifting speeds of 2.7m/min on low speed and 0.9m/min on high speed, it is built for optimal performance in demanding environments. Featuring a pressed steel structure for strength, the hoist also incorporates high-tensile alloy steel top and bottom hooks for added durability and safety. The 11.2mm grade 80 alloy steel load chain ensures secure lifting, while limit switches prevent chain runout. Rated IP54 for the hoist and IP65 for the control, this hoist is built to withstand dust and water exposure. It complies with ASNZS 1418.2 standards and offers the flexibility to re-chain to your specific requirements (limits apply), making it an excellent choice for industrial applications.
Features
- 5T (5000kg) capacity with a 3m standard lift
- 3.0kW dual-speed 3-phase motor with lifting speeds of 2.7m/min (low) and 0.9m/min (high)
- High-tensile alloy steel hooks for strength and safety
- 11.2mm grade 80 alloy steel load chain for enhanced durability
- Limit switches to prevent chain runout
- IP54 rated hoist and IP65 rated control for dust and water protection
- Complies with ASNZS 1418.2 safety standards
- Option to re-chain to your required length (limits apply)
- Heavy-duty, compact design for efficient handling and operation
NOTE: This product is available exclusively online and ships directly from the supplier's warehouse
