1" BALL X KNUCKLE CAT 2 MOUNT LOCK VALVE 130 - 170HP TRACTOR

Product Code: TLH1

Detail
Downloads

Power your tractor's three-point-linkage system with a quality Motus® Ball-Ball category 2 hydraulic top link.

Features

Fitted with lock-valve to stop cylinder creep
Quality components for long trouble-free operation
3/8" BSPP-F valve ports

Specifications

Stroke	250mm
Closed centre measurement	654mm
Open centre measurement	904mm
Ports	3/8" BSPP-Female
Base Mount	Knuckle 1"
Shaft Mount	1" Ball End (Cat2)
Force Extension	7060kG @ 2250psi
Force Retraction	5300kG @ 2250psi
