FESTO Filter Regulator 1/4" – MS4-LFR-1/4-D7-ERV-AS
This compact filter regulator with fully automatic condensate drain and integrated pressure gauge ensures clean, stable air supply for pneumatic systems. Designed for versatility, it supports front panel or in-line installation and is suitable for food-safe applications.
Features
- Fully automatic condensate drain for hands-free operation
- Integrated pressure gauge for easy monitoring
- 40 µm filtration for efficient air purification
- Rotary knob with detent for secure adjustment
- Plastic bowl guard for durability
- Maintains constant output pressure with secondary venting and return flow
- Suitable for vertical mounting
Specifications
- Size: 4
- Series: MS
- Filtration Grade: 40 µm
- Max Condensate Volume: 19 ml
- Operating Pressure: 2–12 bar
- Pressure Regulation Range: 0.5–12 bar
- Flow Rate: 1500 L/min (DIN 1343)
- Operating Medium: Compressed air or inert gases (ISO 8573-1:2010)
- Air Purity at Outlet: ISO 8573-1:2010 [7:4:4]
- Degree of Condensate Separation: >75%
- Media & Ambient Temperature: -10°C to 60°C
- Corrosion Resistance: CRC2 (Moderate)
- Mounting: Front panel or in-line with accessories
- Port Size: G1/4
- Housing & Sub-base Material: Die-cast aluminium
- Bowl Material: PC
- Seals: NBR
- Filter Material: PE
- Membrane Material: NBR
- Control Panel Material: PA / POM
- Separating Plate Material: POM
- Weight: 275 g
- RoHS Compliant
