Case-IH® Compatible Extended Wear Clean Grain Elevator Head & Wear Plate

Repair the clean grain discharge system on your combine with this C&M made in Australia extended wear elevator head assembly. Designed for compatible Case-IH® Flagship Axial-Flow combines, this direct-fit replacement helps protect a high-impact section of the clean grain elevator from abrasive grain flow and premature wear.

Manufactured by C&M at our engineering facility in Griffith, NSW, the assembly includes the 47816431 elevator head with the 87733824 stainless steel wear plate pre-installed. The heavy-duty stainless steel construction provides improved corrosion and abrasion resistance compared with a standard painted carbon steel assembly.

Supplying the elevator head and wear plate as a complete assembly helps simplify installation while providing an extended wear solution for the clean grain discharge area. The finished internal surface supports smooth grain movement into the grain tank while helping reduce wear at the primary impact point.

Case-IH® OEM Cross-Reference

• Main Assembly: Replaces OEM 47816431.
• Pre-Installed Wear Plate: Replaces OEM 87733824.
• Related OEM References: 87584809, 87733833 and 51663620.

Compatible Case-IH® Combine Harvesters

Confirm the combine model, serial number and existing elevator-head configuration before ordering.

Technical Specifications & Features

• Product Type: Clean grain elevator head and wear plate assembly.
• Manufacturer: C&M made in Australia at our Griffith, NSW engineering facility.
• Material: Heavy-duty stainless steel for improved abrasion and corrosion resistance.
• Wear Rating: Extended wear configuration for high-capacity grain-handling applications.
• Supplied Assembly: 47816431 elevator head with the 87733824 wear plate pre-installed.
• Application: Upper clean grain elevator discharge area on compatible Case-IH® Flagship combines.
• Fitment: Precision manufactured as a direct-fit replacement for the listed applications.
• Top Door: Not included; use C&M part number CM51664927 where a replacement door is required.
• Shipping: Available for fast Australia-wide shipping from Collier & Miller.

The C&M Difference

C&M made in Australia parts are developed around the fit and function of the original component. Critical dimensions, mounting points and related component fitment are checked to provide a practical direct-fit replacement. Stainless steel construction also provides an extended wear alternative for an area exposed to continuous high-volume grain movement.

Expert Maintenance Review

The clean grain elevator head is the final transition point before harvested grain enters the grain tank. Grain discharged by the elevator paddles repeatedly strikes the internal wear surface, making the head and wear plate important inspection points during pre-harvest maintenance.

Inspect the existing assembly for thin sections, polished wear areas, cracking, loose mounting points and grain leakage. Check the elevator chain, paddles, upper sprocket, bearings and shaft at the same time. Excessive chain movement or damaged paddles can accelerate wear inside the replacement head.

Installation Tip

Compare the mounting points and discharge opening with the original assembly before installation. Once fitted, confirm that the elevator chain and paddles run centrally through the head, check internal clearance and rotate the system by hand before operating the combine.

Case-IH® names and OEM part numbers are used for identification and compatibility reference purposes only. This is an aftermarket replacement product and is not represented as a genuine Case-IH® component.
