FESTO MS6-LFR-1/2-D7-ERV-AS Filter Regulator with Automatic Drain and Pressure Gauge
The FESTO MS6-LFR-1/2-D7-ERV-AS provides clean, regulated compressed air with minimal maintenance thanks to its fully automatic condensate drain. Designed for reliable performance in industrial systems, it features a 40 µm filtration grade, integrated pressure gauge, and durable construction, ensuring consistent air quality and precise pressure control.
Features
- Filter regulator with integrated pressure gauge for easy monitoring
- Fully automatic condensate drain for maintenance-free operation
- Rotary knob actuator lock with detent for safe adjustment
- Plastic bowl guard for operator and component protection
- Maintains constant output pressure with secondary venting
- Flexible mounting options: front panel or in-line
Specifications
- Series Size: 6
- Operating Pressure: 2–12 bar
- Pressure Regulation Range: 0.5–12 bar
- Nominal Flow Rate: 4500 l/min (DIN 1343)
- Max. Condensate Volume: 38 ml
- Filtration Grade: 40 µm
- Degree of Condensate Separation: >75%
- Pneumatic Connections: G1/2 port 1 and 2
- Operating Medium: Compressed air (ISO 8573-1 [7:4:-]) and inert gases
- Air Purity Class: ISO 8573-1 [7:4:4]
- Temperature Range: -10°C to +60°C
- Housing Material: Die-cast aluminium
- Bowl Material: PC
- Control Panel Material: PA POM
- Seal Material: NBR
- Product Weight: 875 g
